Reliable 18650 Li-ion BatteryThe Weijiang ICR18650 Li-ion Battery is engineered to deliver reliable power for high-drain devices. With a capacity of 2600mAh and a voltage of 3.7V, it ensures long-lasting energy and stable performance for a wide range of applications. High Capacity and Long LifeThis battery boasts a high capacity of 2600mAh, providing extended use between charges. Its robust construction ensures a long cycle life, making it a cost-effective solution for your power needs. Wide Range of ApplicationsIdeal for use in:
|
| Nominal specifications | |||||||||||||||||||||||
| Item | Specification | ||||||||||||||||||||||
| Nominal discharge capacity | 2,500mAh Charge: 1.25A, 4.20V,CCCV 125mA cut-off, Discharge: 0.2C, 2.5V discharge cut-off |
||||||||||||||||||||||
| Nominal voltage | 3.6V | ||||||||||||||||||||||
| Standard charge | CCCV, 1.25A, 4.20 ± 0.05 V, 125mA cut-off | ||||||||||||||||||||||
| Rapid charge | CCCV, 4A, 4.20 ± 0.05 V, 100mA cut-off | ||||||||||||||||||||||
| Charging time | Standard charge : 180min / 125mA cut-off Rapid charge: 60min (at 25℃) / 100mA cut-off |
||||||||||||||||||||||
| Max. continuous discharge (Continuous) |
20A(at 25℃), 60% at 250 cycle | ||||||||||||||||||||||
| Discharge cut-off voltage End of discharge |
2.5V | ||||||||||||||||||||||
| Cell weight | 45.0g max | ||||||||||||||||||||||
| Cell dimension | Height: 64.85 ± 0.15mm Diameter : 18.33 ± 0.07mm |
||||||||||||||||||||||
| Operating temperature (surface temperature) |
Charge : 0 to 50℃ (recommended recharge release < 45℃) Discharge: -20 to 75℃ (recommended re-discharge release < 60℃) |
||||||||||||||||||||||
Storage temperature (Recovery 90% after storage) |
1.5 year -30~25℃(1*) 3 months -30~45℃(1*) 1 month -30~60℃(1*) |
||||||||||||||||||||||
Customize for Lithium Batteries:
The below Lithium batteries list is only for reference. Other Lithium batteries with different specifications are also available. Customized Lithium batteries and battery packs are available. Contact us for more detailed information. We have rich experience from battery concept to production seamlessly and on budget. |
||||||
| Model | Nominal Capacity | Nominal Voltage |
Dimension(mm) | Weight | ||
| Typical | Min | Diameter | Height | Approx | ||
| （mAh） | （mAh） | （V） | (mm) | (mm) | (g) | |
| ICR08200 | 80 | 75 | 3.7 | 8.4 | 22 | 2.9 |
| ICR08600 | 300 | 280 | 3.7 | 8.4 | 60.5 | 9 |
| ICR10120 | 50 | 45 | 3.7 | 10.2 | 11.2 | 2.4 |
| ICR10160 | 120 | 110 | 3.7 | 10.2 | 16.5 | 5 |
| ICR10430 | 320 | 300 | 3.7 | 10.2 | 42.5 | 9 |
| ICR10440 | 320 | 300 | 3.7 | 10.2 | 43.5 | 9 |
| ICR14430 | 650 | 620 | 3.7 | 14.1 | 43 | 17 |
| ICR14500 | 750 | 720 | 3.7 | 14.1 | 50.5 | 18 |
| ICR14500 | 850 | 820 | 3.7 | 14.1 | 50.5 | 19 |
| ICR145650 | 1100 | 1050 | 3.7 | 14.1 | 65.5 | 24 |
| ICR17280 | 600 | 550 | 3.7 | 16.5 | 28.5 | 15 |
| ICR17335 | 700 | 650 | 3.7 | 16.8 | 34.5 | 18 |
| ICR17500 | 1100 | 1050 | 3.7 | 16.8 | 50.5 | 27 |
| ICR17650 | 1600 | 1500 | 3.7 | 16.8 | 65.5 | 36 |
| ICR18490 | 1400 | 1350 | 3.7 | 18.3 | 49.5 | 32 |
| ICR18650 | 1400 | 1350 | 3.7 | 18.3 | 65.5 | 40 |
| ICR18650 | 1600 | 1550 | 3.7 | 18.3 | 65.5 | 41 |
| ICR18650 | 1800 | 1750 | 3.7 | 18.3 | 65.5 | 43 |
| ICR18650 | 1900 | 1850 | 3.7 | 18.3 | 65.5 | 43 |
| ICR18650 | 2000 | 1950 | 3.7 | 18.3 | 655 | 43 |
| ICR18650 | 2100 | 2050 | 3.7 | 18.3 | 65.5 | 44 |
| ICR18650 | 2200 | 2150 | 3.7 | 18.3 | 65.5 | 45 |
| ICR18650 | 2400 | 2350 | 3.7 | 18.3 | 65.5 | 45 |
| CR123A | 600 | 550 | 3.7 | 16.5 | 34 | 20 |
