CR2320 Lithium Coin Cell | Weijiang Power

The CR2320 battery is a small, cylindrical lithium coin cell battery. It has a diameter of 23mm and a thickness of 2.0mm. This type of battery is commonly used in small electronic devices such as calculators, remote controls, and digital watches. It has a voltage of 3 volts and a capacity of approximately 150 milliampere-hours (mAh).
  • CR2320 Lithium Coin Cell | Weijiang Power
  • CR2320 Lithium Coin Cell | Weijiang Power
  • CR2320 Lithium Coin Cell | Weijiang Power
Description


Key Features:

  • CR2320 Battery Diameter: 23mm
  • CR2320 Battery Height: 2.0 mm
  • CR2320 Battery Voltage: 3.0 V
  • CR2320 Battery Chemistry: Lithium Manganese Dioxide (Li-Mn02)
  • CR2320 Battery Capacity (mAh): 210 mAh

Specification for NiMH Batteries:

Below NiMH batteries list are only for reference. Other options are also available.
Customized NiMH battery and battery pack is available, CONTACT US for more detailed information. We have rich experience from battery concept to production, seamlessly, and on-budget.
Let Weijiang Be Your Battery Pack Manufacturer!




Model   Nominal
Voltage
(V)
Standard
Capacity
(mAh)

Termination Voltage (V)   Maximum Continuous Current (mA)   Maximum Pulse  Current(mA) Diameter
(mm)
Height
(mm)
Weight of Unit Cell
(g)
CR927 3.0 30 2.0 0.2 5 9.5 2.7 0.6
CR1025 3.0 30 2.0 0.2 5 10.0 2.5 0.8
CR1130 3.0 40 2.0 0.2 5 11.6 3.0 1.0
CR1212 3.0 18 2.0 0.2 5 12.5 1.2 0.6
CR1216 3.0 25 2.0 0.2 5 12.5 1.6 0.7
CR1220 3.0 40 2.0 0.2 5 12.5 2.0 0.8
CR1225 3.0 48 2.0 0.2 5 12.5 2.5 0.9
CR1616 3.0 50 2.0 0.3 8 16.0 1.6 1.2
CR1620 3.0 70 2.0 0.3 8 16.0 2.0 1.3
CR1625 3.0 90 2.0 0.3 8 16.0 2.5 1.8
CR1632 3.0 120 2.0 0.3 10 16.0 3.2 2.3
CR2016 3.0 75 2.0 0.3 10 20.0 1.6 1.7
CR2025 3.0 150 2.0 0.5 15 20.0 2.5 2.4
CR2032 3.0 210 2.0 0.75 15 20.0 3.2 3.0
CR2320 3.0 130 2.0 0.75 15 23.0 2.0 4.0
CR2330 3.0 260 2.0 0.75 15 23.0 3.0 4.0
CR2354 3.0 530 2.0 1 15 23.0 5.4 5.8
CR2430 3.0 270 2.0 1 15 24.5 3.0 4.5
CR2450 3.0 550 2.0 1
5 24.5 5.0 6.5
CR2477 3.0 950 2.0 1 15 24.5 7.7 9.5
CR3032 3.0 580 2.0 1 15 30.0 3.2 6.8
CR123A 3.0 1300 2.0 1500 3000 17.0 33.5  16
